Mobile Screening Plant

Mobile Screening Plant is widely used in road and bridge construction, urban construction, building garbage disposal, mining, coal, metallurgical, energy and other departments for crushing and screening operations.

Applications: Stone crusher is used for crushing over 120 kinds of rocks, such as limestone, granite, quartz, basalt, river stone, gold ore, iron ore, coal, gravel, aggregate etc. Different final output size could meet your different needs.

50-300 t/hCapacity 120-500kwMotor Power

+86-13598805827*24-hourWhatsapp/Wechat

Request a Quotation

01Product Features

Mobile Screening Plant is a high-effective screening equipments. It adopts the type of self-driving with advanced technology and complete functions. No matter where It can arrive any places at working site, which can save much time that should process materials and be easy to be cohered with accessory machinery. Usually it can come into use without electronic power or crude oil engine as long as it is transported to working site. ;Its opsonization design makes the machine has the advantages of high-productivity and well-distributed discharge.

Mobile Screening Plant
Mobile Screening Plant
Mobile Screening Plant


02Product Features

  • Mobile screening plant integrate receiving materials, screening, conveying and other processing equipments.

  • It has excellent performance of screening rock and producing aggregate by optimizing technological process.

  • It can form a complete crushing plant combined with other crushing equipments.

  • High Yield.

    Compared with fixed crushing and screening plant, it has more advantages, such as advanced design program, good performance and high efficiency, easy maintenance and lower operation cost.

Mobile Screening Plant

03Working Principle

Mobile Screening Plant

mobile screening plant is widely used in all kinds of quarries, screening of construction wastes and mineral working, etc. The most optimized design and the capability of climbing work can meet the different needs of working sites, also give it the advantage of environment friendly: low noise, compact composition, flexible to move. The effective exhaust system and pollution discharging system, and advanced preliminary screening devices greatly improve the screening efficiency.

04Technical Parameters

Mobile Screening Plant

Item Unit M3S1848 M3S1860 M3S2160
Transportation Length mm 10100 11100 11100
Transportation Width mm 2800 2820 3100
Transportation Height mm 4350 4350 4350
Maximum Length mm 11100 11800 11800
Maximum Width mm 3600 3600 3970
Maximum Height mm 6000 6500 6500
Weight t 16 18 19
Tire Configuration   Dual-axial Dual-axial Dual-axial
Discharging Belt Conveyor   B800X7M B800X8M B1000X8M
Vibrating Screen   3YZS1848 3YZS1860 3YZS2160

05Working Principle

+86-13598805827*24-hourWhatsapp/Wechat

Request a Quotation

Note: the above is the display of finished materials, which can be used for crushing more than 200 kinds of materials at the same time

06There are a wide range of crushers to meet your various needs

Crawler Crushing Station

Feed Size:350~425mm

Learn More

Crawler Jaw Crushing Station

Capacity:10-450 t/h

Learn More

Mobile Jaw Crusher Plant

Capacity:10-450 t/h

Learn More
